5820XL Addressable Fire Alarm Control System

DESCARGAR ARCHIVO PDF
Código: AV-KPD608

ESPECIFICACIONES:

Up to 508 addressable points.
• Uses standard wire—no shielded or twisted pair required.
• Built-in digital communicator.
• Central station reporting by Point or by Zone.
• Built-in synchronization for appliances from AMSECO®, Gentex®, Faraday, and Wheelock®
• Supports Class B (Style 4) and Class A (Style 6) configuration for SLC, SBUS, and Flexput circuits.
• Distributed, intelligent power.
• Drift compensation.
• Flexput™ I/O circuits.
• Eight pre-programmed output cadences, (including ANSI-3.41), and 4 programmable outputs.
• Built-in annunciator with 80- character LCD display.
• RS-485 bus provides communication to system accessories.
• Built-in RS-232 interface for programming via PC.
• Built-in Form C trouble relay rated at 2.5 amps at 24 VDC.
• Two built-in Form C programmable relays rated at 2.5 amps at 24 VDC.
• Supports Sounder Bases.
